| acc. to Standard | MIL-C-17 | |
| CONSTRUCTION DATA | ||
| Inner Conductor | Ø mm | 0,90 19x0,18 |
| material | CUSn | |
| Dielectric | Ø mm | 2,95 |
| material | PE | |
| Braid | material | CuSn |
| Braid Optical Coverage | % | 93 |
| Diameter over Braid | Ø mm | 3,43 |
| Outer Sheath | Ø mm | 5 |
| material | PVCII | |
| PHYSICAL DATA | ||
| Copper Content | kg/km | 16,6 |
| Cable Weight | kg/km | 35,9 |
| Min bending radius x 1/n | mm | 25/50 |
| Max.Tensile Strength | N | 90 |
| ELECTRICAL DATA | ||
| Impedance | Ohm | 50±2 |
| Capacitance (@1kHz) | pF/m | 100 ± 2 |
| Velocity Ratio | % | 66 |
| Attenuation (at 20°C ) | ||
| at 50 MHz | dB/100m | 10,7 |
| at 200 MHz | dB/100m | 23,5 |
| at 300 MHz | dB/100m | 29,6 |
| at 470 MHz | dB/100m | 38,7 |
| at 800 MHz | dB/100m | 53,38 |
| at 1000 MHz | dB/100m | 61,1 |
| Structural return loss (SRL) | ||
| at 30 - 300 MHz | dB | >26 |
| at 300 - 600 MHz | dB | >25 |
| at 600 - 1000 MHz | dB | >24 |
| Screening Attenuation (SA) | Class | |
| at 30 - 1000 MHz | dB | >50 |
| DC Conductor Resistance inner/outer | Ohm/km | 38,5 / 16,5 |
| Loop resistance | Ohm/km | 55,0 |
| Sheat Insulation voltage (spark test) | kV |
